11 Leaf Spring 8/2PD/3

Model: Freightliner 46-1193
Weight: 156.40lb
SKU: 46-1193
MPN: 6803200205

Based on 0 reviews. - Write a review

$515.00

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

NOTE: Please allow 4-6 weeks minimum for manufacturing time that does not include shipping time! Our springs are hand-built to order for your vehicle. All orders are custom, they are non-refundable after payment due to steel allocation for your build. Shipping varies upon location.

Specifications

Attribute	Description
Spring Style	Multi-Leaf Spring
Spring Eye	NO
Eye Type (S.E./L.E)	HK-2/---
Width	3
S.E. (A)	29-1/2
L.E (B)	29-1/2
Bushing A End (S.E.)	HK-2
Bushing B End (L.E.)	---
Nos.Leaves	11
Arch (C)	3-1/4
Capacity	7700
Notes (B.O.M)	3x6/590 6/447*29-1/2 C:3-1/4 HK-2---
Center Bolt Size	1/2 x 6-3/4
Center Bolt Head Size	3/4D x 7/16H
MFG	Freightliner

Similar Products

Part #	# of Leaves	Arch	Cap.	Bushing A End/ B End	Notes (B.O.M)
46-1189	13	3	10150	HK-2/---	3x8/590 2/473 1/360 1/447 1/360*29-1/2x29-1/2 C:3> HK-2/---
46-1189HD	12	3-3/8	14000		3x10/662 RR 2/499 29-1 2x 29-1/2 C3-3/8 EL TPG-b
46-1193	11	3-1/4	7700	HK-2/---	3x6/590 6/447*29-1/2 C:3-1/4 HK-2/---

*Must replace in pairs when using alternate leaf springs*

Where Used

Name	Type
Freightliner Rear MB, FL 60/70/80/106 M2BC MT55, Single Axle	Suspension

Cross Reference

Name	OEM Part Number	Notes
Freightliner	6803200205	11 Leaf Spring 8/2Pd/3
Freightliner	680-320-02-05	11 Leaf Spring 8/2Pd/3

There are no downloads for this item.

11 Leaf Spring 8/2PD/3
