3 Leaf Parabolic Spring

3 Leaf Parabolic Spring
3 Leaf Parabolic Spring
  • Model: Freightliner 46-1764
  • Weight: 154.00lb
  • Dimensions: 60.00in x 7.00in x 12.00in
  • SKU: 46-1764
  • MPN: A1615293000
Based on 0 reviews. - Write a review
$716.00
Add to Cart
Buy Now Ask Question
Add to Wish List Compare this Product
NOTE: Please allow 4-6 weeks minimum for manufacturing time that does not include shipping time! Our springs are hand-built to order for your vehicle. All orders are custom, they are non-refundable after payment due to steel allocation for your build. Shipping varies upon location.

Specification

Attribute Value
Spring Type Parabolic Spring
Leaf Type Uses Parabolic Extra Leaf TXL468
Spring Eye 2
Eye Type (S.E./L.E.) STD/STD
Width 4
S.E. (A) 26-1/16
L.E. (B) 30
Bushing A End (S.E.) RB263, MR772
Bushing B End (L.E.) RB263 MR772
Nos. Leaves 3
Arch (C) 5
Capacity 10,000
MFG Freightliner
Notes (B. O. M) 4X3/887*26-1/16X30 C:5 RB263/RB263
Center Bolt Size 1/2 X 3-1/2
Center Bolt Head Size 3/4D X 7/16H

Similar Products

Part # # of Leaves Arch Cap. Bushing A End/ B End Notes (B.O.M)
46-1494 3 6-1/16 7300 RB263/RB233 4X3/702*26X30 C:6-1/16 RB263/RB233
46-1494OE 3 6-1/16 7300 RB263/RB233 4X3/702*26X30 C:6-1/16 RB263/RB233
46-1496 3 5-7/8 8000 RB263/RB263 4X3/788*26X30 C:5-7/8 RB263/RB263
46-1498 3 5-9/16 9000 RB263/RB263 4X3/788*26X30 C:5-9/16 RB263/RB263
46-1764 3 5 10000 RB263/RB263 4X3/887*26-1/16X30 C:5 RB263/RB263

*Must replace in pairs when using alternate leaf springs*

Where Used

Name Type
Freightliner Front Freightliner FC, FL, FL112, FLD (w5/56: Spg.) (Revised) Suspension
Western Star Front Freightliner Chassis Suspension

Cross Reference

Name Part Number Notes
Freightliner A1615293000 3 Leaf Parabolic Spring
Freightliner A16-15293-000 3 Leaf Parabolic Spring
Hendrickson 51960 3 Leaf Parabolic Spring
Hendrickson 52982 3 Leaf Parabolic Spring
