4 Leaf Parabolic Spring PD/4

4 Leaf Parabolic Spring PD/4
4 Leaf Parabolic Spring PD/4
  • Model: Freightliner 46-1294
  • Weight: 164.00lb
  • Dimensions: 57.00in x 6.00in x 11.00in
  • SKU: 46-1294
  • MPN: A1613420001
Based on 0 reviews. - Write a review
$656.00
Add to Cart
Buy Now Ask Question
Add to Wish List Compare this Product
NOTE: Please allow 4-6 weeks minimum for manufacturing time that does not include shipping time! Our springs are hand-built to order for your vehicle. All orders are custom, they are non-refundable after payment due to steel allocation for your build. Shipping varies upon location.

Specification

Attribute Value
Spring Type Parabolic Spring
Leaf Type Uses Parabolic Extra Leaf TXL462
Spring Eye 2
Eye Type (S.E./L.E.) STD/STD
Width 4
S.E. (A) 26-1/8
L.E. (B) 28-3/4
Bushing A End (S.E.) RNK, MBRNK
Bushing B End (L.E.) RNK, MBRNK
Nos. Leaves 4
Arch (C) 5-1/8
Capacity 10,000
MFG Freightliner
Notes (B. O. M) 4x1/323 4/788*26-1/8x28-3/4 C:5-1/8 RNK/RNK
Center Bolt Size 1/2 X 4-1/2
Center Bolt Head Size 3/4D X 7/16H

Similar Products

Part # # of Leaves Arch Cap. Bushing A End/ B End Notes (B.O.M)
46-1280 2 6-5/16 6000 RNK/RNK 4X2/558 2/788 1/323*26-1/8X29 C:6-5/16 RNK/RNK
46-122 3 5-1/8 6000 TB26-b/TB26-b 4X5/447 4/401*25X29 C:5-1/8 TB26-b/TB26-b
46-220 3 7-1/2 5500 RNK/RNK 4X1/323 3/662*26-1/8X28-7/8 C:7-1/2 RNK/RNK
46-1260 3 5-1/4 6500 RNK/RNK 4X1/401 3/750*26X28-7/8 C:5-1/4 RNK/RNK
46-1294 4 5-1/8 10,000 RNK/RNK 4X1/323 4/788*26-1/x28-3/4 C:5-1/8 RNK/RNK

*Must replace in pairs when using alternate leaf springs*

Where Used

Name Type
Freightliner Front 4.0" Wd.; FLA, FLB, FLL, FLT (COE & LCF); FLC120 (Conv.) Revised Suspension

Cross Reference

Name Part Number Notes
Freightliner A1613420001 4 Leaf Parabolic Spring Pd/4
Freightliner A16-13420-001 4 Leaf Parabolic Spring Pd/4
Freightliner A1614012000 4 Leaf Parabolic Spring Pd/4
Freightliner A16-14012-000 4 Leaf Parabolic Spring Pd/4
Hendrickson 51240 4 Leaf Parabolic Spring Pd/4
