8 Leaf Spring
8 Leaf Spring
- Model: Freightliner 46-1355
- Weight: 170.30lb
- SKU: 46-1355
- MPN: A1614413000
$538.05
NOTE: Please allow 4-6 weeks minimum for manufacturing time that does not include shipping time! Our springs are hand-built to order for your vehicle. All orders are custom, they are non-refundable after payment due to steel allocation for your build. Shipping varies upon location.
Specification
| Attribute | Value |
|---|---|
| Spring Style | Multi-Leaf Spring |
| Spring Eye | NO |
| Eye Type (S.E./L.E.) | - - -/- - - |
| Width | 3 |
| S.E. (A) | 30-5/16 |
| L.E. (B) | 30-5/16 |
| Bushing A End (S.E.) | - - - |
| Bushing B End (L.E.) | - - - |
| Nos. Leaves | 8 |
| Arch (C) | 2-15/16 |
| Capacity | 12,500 |
| MFG | Freightliner |
| Notes (B. O. M) | 3X7/702*30-5/16X30-5/16 C:2-15/16 - - -/- - - |
| Center Bolt Size | 1/2 X 6-1/2 |
| Center Bolt Head Size | 3/4D X 7/16H |
Similar Products
| Part # | # of Leaves | Arch | Cap. | Bushing A End/ B End | Notes (B.O.M) |
|---|---|---|---|---|---|
| 46-169 | 7 | 3-1/8 | 8800 | ---/--- | 3X7/702*30-5/16X30-5/16 C:3-1/8 ---/--- |
| 7 |
3-1/8 |
10150 |
---/--- |
3X7/702*30-5/16X30-5/16C:3-1/8---/--- | |
| 46-1209 | 6 | 3-1/8 | 8800 | ---/--- | 3X6/702 1/360*30-5/16X30-5/16 C:3-1/8 ---/--- |
| 7 |
2-15/16 |
26000 |
---/--- |
3X1/662 1/499*20X20 C:4 - - -/- - - |
*Must replace in pairs when using alternate leaf springs.*
Over Load
| Part # | # of Leaves | Arch | Cap. | Bushing A End/ B End | Notes (B.O.M) |
|---|---|---|---|---|---|
| 1 | 3-1/16 | 2500 | ---/--- | 3X1/662 1/499*20X20 C:3-1/16 - - -/- - - | |
| 1 | 4 |
---/--- | 3X1/662 1/499*20X20 C:3-1/16 - - -/- - - |
Where Used
| Name | Type |
|---|---|
| Freightliner Rear Single Axle 3.0" Wide, '01 & Up | Suspension |
Cross Reference
| Name | Part Number | Notes |
|---|---|---|
| Freightliner | A1614413000 | 8 Leaf Spring |
| Freightliner | A16-14413-000 | 8 Leaf Spring |
| Freightliner | 81591000 | 8 Leaf Spring |
| Freightliner | 81591-000 | 8 Leaf Spring |
There are no downloads for this item.
